Product Details
Rugged design stands up to field use
Measures/Sources volts, mA, RTDs, thermocouples, frequency, and ohms
0.02% output and measurement accuracy
Easy-to-read measure/source screen lets you view input and output simultaneously
Perform fast linearity tests with auto step and auto ramp features
Powers transmitters during the test using a loop supply with simultaneous mA measurement
Measures and outputs 10 types of RTDs and 12 types of TC signals
Rechargeable Ni-MH battery
Adjustable brightness provides better visibility in poor light
Store frequently-used test setups for later use
Low battery indicator and auto shut-off
Specifications
- Portable/Bench top Portable
- Data Logging/ Without Data Logging Without Data Logging
- No. of Processes 5
Additional Specifications
- DC Voltage Range: 50, 500mV, 30V (upper display), 50V (lower display); Resolution: 0.001, 0.01, 1mV, 0.001V; Accuracy: 50mV: ±(0.02% +10), 500mV: ±(0.02% +5), 30V (upper display): ±(0.02% +2), 50V (lower display): ±(0.02% +2)
- DC Current Range: 20mA at 0 to 24mA, Resolution: 0.001mA, Accuracy: ±(0.02% +2)
- Loop Current Range: 20mA (loop) at 0 to 24mA, Resolution: 0.001mA, Accuracy: ±(0.02% +2)
- Resistance Range: 500, 5000Ω, Resolution: 0.01, 0.1Ω, Accuracy: ±(0.05% +10)
- Frequency Range: 100Hz, 1, 10, 100kHz, Resolution: 0.01, 0.1, 1Hz, Accuracy: ±(0.01% +1)
- Includes Multifunction Process Calibrator; Test Leads; Test Clips; Type K Thermocouple Wire Probe; USB Cable; Power Adapter; Carrying Case
