Product Details
High impact gear case and brake cover for heavy duty service
Caged ball bearings on load sprocket for the ultimate in smooth, easy operation
Dual pawl Weston-style brake features extra heavy pawl springs for reliable and safe operation
Exclusive premium grade, non-asbestos brake discs for longest life
Top and bottom safety hooks bend to warn of overloads
Cast steel safety latches exceed industry standards
Deformation indicators on hooks allow accurate measurement for easy maintenance
Load tested to 150% of rated capacity with certificate
Specifications
- Capacity 3000 lbs. (1.5 tons)
- Lift 5'
Additional Specifications
- Standard(s) Met ISO 9001-2000, ASME B30.21
- Load Chain Diameter 7.1 mm
- Load Chain Grade 100
- Number of Falls 1
- Min. Distance Between Hooks 13-3/4"
- Force Required to Lift 46 lbs.
- Lever Length 16-1/4"
