Product Details
Carbide ball bearing blade guides
Centralized 24 V control panel and automatic shut-off
Adjustable hydraulic down feed control
Tru-Lock ™ cam lock and quick positioning vise system with fully adjustable jaws for 0° to 45° angled cuts
To ensure reliable accurate cuts, both adjustable control arms can be positioned as close to the cut as possible
Coolant system with regular valves provide an even flow of coolant to the blade
Specifications
- Cutting Capacity at 90° Round 10" and 10" x 18" Rectangular
- Cutting Capacity at 45° Round 10" and 7" x 9-3/8" Rectangular
- No. of Speeds 4
- Overall Width 27"
- Overall Length 70"
- Overall Height 42"
- Style Horizontal
Additional Specifications
- Speeds 4 (114, 196. 288, 377 FPM)
- Blade 122" x 1" x 0.032"
- Motor 2 HP, 2.6 A, 3 phase, 60 Hz
- Voltage 600 V
- Weight 634 lbs.
